ISO834-1 EN1363-1 Fireproof Coating Sample Fire Resistance Test Furnace Test Machine Supplies

warranty : 1 Year

customized support : OEM, ODM, OBM, Software reengineering

place of origin : Guangdong, China

brand name : DAXIAN

power : 240kw

Accuracy : ≤ 5%

Voltage : 380V

Type : Testing machine

Application : process testing

Protection Class : ip65

Machine name : ISO834-1 Steel Structure Fireproof Coating Test Furnace

Standard : ISO834-1,EN1363-1

Test sample : building components and accessories

Materials : Stainless steel, steel, high-temperature bricks, ceramic wool

Power : AC220, 0.3kw high temperature resistant high-pressure fan

Operation temperature : Below 1300 ℃

Dimension(L*W*H) : L160*W160*H160CM

Fuel : Natural gas (calorific value 8500Kcal/Nm3) or industrial gas

Power supply : 380V / 50HZ

Warranty : 12 months

Price : CN¥35,714.50/boxes >=1 boxes

Contact Now

Company Profile

ISO834-1 EN1363-1 Fireproof Coating Sample Fire Resistance Test Furnace Test Machine Supplies

DAXIAN INTERNATIONAL EQUIPMENT CO., LTD is Located in Dongguan City, Guangdong Province, China, we are a high tech enterpris which is specialized in development and manufacturing, The most professional OEM manufacturer in the country,we mainly produce Fire Testing Equipment, Construction Materials Testing Equipment, Plastic Testing Equipment, Wire Testing Equipment, Environmental Test Chamber, Tensile Testing Machine, and others DAXIAN's testing equipment is widely used in various fields: scientific institutions, colleges, inspection institutions, auto parts, electronics, electronics, LEDs, photoelectricity, mobile, plastic rubber, telecommunications, chemical industry, aerospace, building materials and products, wire and cable, textile and fabric, etc. All DAXIAN testing equipment is designed according to international test standards, such as ISO, ASTM, DIN, EN, GB, BS, JIS, UL, TAPPI, AATCC, IEC, VDE, CSA, CEN, and so on.

Specification

Item	Value
Warranty	1 Year
Customized support	OEM, ODM, OBM, Software reengineering
Place of Origin	China
	Guangdong
Brand Name	DAXIAN
Voltage	380V
Power	Electronic
External dimensions	L160W160H160CM
Weight	700kg
Power	60-80KW
Standard	ISO834-1、EN1363-1
Protection Class	ip57

Scope of application:

It is suitable for determining the fire resistance characteristics of horizontal building components such as walls, beams, columns, floor slabs and suspended ceilings under standard fire conditions.

Standard:

ISO834-1、EN1363-1

Specification:

Test device technical indicators and instructions:

⑴ Test products: building components and accessories

⑵ Inner dimension:width×depth×height = 1000×1000×1000mm External dimensions: width×depth×height = 1600×1600×1600mm(approx.)

(3)Fuel:natural gas or liquefied petroleum gas

(4)Working temperature: design limit temperature 1300 ℃, long-term working temperature 1200℃, Increase the temperature according to the set formula.

(5)Appearance temperature rise of the device: ≤55 ℃

(6)Temperature measurement: 4 K-type nickel-chromium-nickel-silicon thermocouples (wire diameter 0.75-1.5mm) thermocouples and 10 thermocouples on the back of the sample in the device.

(7)Pressure measurement: 3 pressure sensors ± 100Pa, micromanometer with an accuracy of ±2Pa.

(8)Combustion method:

4 spray guns are installed horizontally on the side (one on the back and two observation holes on theside).

(9)Spray gun power: 60KW per side.

Products Description

Packing & Delivery

FAQ

Q:Are you factory or trading company?
A:We are factory in Dongguan City, Guangdong Province,China.Near Shenzhen or Guangzhou.

Q:What kind of certificate you have?

A:ISO9001 Certification, CE Certification.

Q:What is the lead time of the product?
A: Generally 7-15 days after getting the deposit.

Q:How about the payment term?
A: T/T, by cash, western union, or L/C.

Q:How about the warranty term?
A:1 year warranty,The engineer can teach the machine on the spot.

Q:. Why should you buy from us not from other suppliers?
A:Advanced technology research and development capabilities, high-quality product manufacturing and testing capabilities, rich
industry experience and professional knowledge, as well as good customer relationships and reputation.
